710nA, Single Rail-to-Rail I/O Operational Amplifier CXAO4299 is guaranteed to operate with a single supply voltage as low as 1.4V, while drawing less than 710nA (TYP) of quiescent current. This devic

   产品概述 返回TOPicf嘉泰姆

The CXAO4299 is guaranteed to operate with a single supply voltage as low as 1.4V, while drawing less than 710nA (TYP) of quiescent current. This device is also designed to support rail-to-rail input and output operation. This combination of features supports battery-powered and portable applications. The CXAO4299 has a gain-bandwidth product of 14.5kHz (TYP) and is unity gain stable. These specifications make this operational amplifier appropriate for low frequency applications, such as battery current monitoring and sensor conditioning. The CXAO4299 is offered in single configuration. The CXAO4299 is available in Green SOT-23-5, SOIC-8 and MSOP-8 packages. It operates over an ambient temperature range of -40℃ to +85℃.

   产品特点 返回TOPicf嘉泰姆

icf嘉泰姆

icf嘉泰姆

• Low Quiescent Current: 710nA (TYP)
• Rail-to-Rail Input and Output
• Gain-Bandwidth Product: 14.5kHz at V_S = 5V (TYP)
• Wide Supply Voltage Range: 1.4V to 5.5V
• Unity Gain Stable
• -40℃</span> to +85℃</span> Operating Temperature Rangeicf嘉泰姆

• Available in Green SOT-23-5, SOIC-8 and MSOP-8 Packagesicf嘉泰姆

   应用范围 返回TOPicf嘉泰姆

icf嘉泰姆

Toll Booth Tags
Wearable Products
Temperature Measurementicf嘉泰姆

Battery Powered Systemicf嘉泰姆

   技术规格书（产品PDF) 返回TOP icf嘉泰姆

     需要详细的PDF规格书请扫一扫微信联系我们，还可以获得免费样品以及技术支持</span>！</span>
